Gerber, ODB++ and IPC-2581 are manufacturing-data handoff formats, not automatic certificates of package completeness. Gerber organizes board images and related fabrication data; ODB++Design uses a structured job package; IPC-2581 uses an XML-based product-data exchange. The practical choice is the format your design system can export correctly and the receiving manufacturing route confirms it can process.

After choosing a format, inspect the exact export, match its revision to drawings, BOM and placement data, and add the project requirements the export did not carry. This guide supports a controlled handoff to PCB manufacturing and, where required, PCB assembly. It does not claim that PCBArise automatically imports every format or version.

The short answer: choose receiver-first, then verify content

Do not select a format from a feature table alone. Ask five questions: Can the EDA tool produce a validated export? Can the recipient process that output in its normal CAM flow? What fabrication, net, component, assembly and test information is actually populated? Which drawings or requirements still sit outside the package? Are all outputs tied to the same approved revision?

A richer data model can reduce manual reconciliation, but it cannot correct an outdated BOM, an ambiguous variant or a missing acceptance requirement. Likewise, a well-built Gerber package can be clear and reliable when layer functions, profile, drill/route information, coordinates and supplemental requirements are controlled.

Illustration of PCB design data, stackup and assembly context at an engineering workstation
Illustration: manufacturing handoff connects PCB geometry, construction, component and assembly information; it is not a photograph of a PCBArise facility or customer project.

What Gerber is designed to transfer

Ucamco maintains Gerber as an open PCB design-data format. Modern Gerber layer files represent copper, solder mask, legend and other board images, while attributes identify file functions and can carry feature metadata. Gerber job data can describe fabrication characteristics such as thickness or finish. The 2026.05 specification also requires a coherent profile and common coordinate behavior for a valid fabrication set.

In practice, teams often release one file per relevant layer plus drill or route data and supporting documents in a ZIP archive. Drill information may be supplied as Gerber/XNC or another agreed NC format depending on the export and recipient. A Gerber set should therefore be judged by its actual contents—not by a filename convention. Confirm the board profile, layer order, polarity, alignment, plated status, units and any separate fabrication drawing, stackup or netlist the receiving route expects.

What ODB++Design is designed to transfer

ODB++Design is stewarded by Siemens as a structured data exchange for moving PCB design information into fabrication, assembly and test. Its hierarchy can carry geometry, layer and drill data, nets, components and process-related attributes within one job package. That organization can help a CAM flow preserve relationships that would otherwise be distributed across separate files.

The important phrase is can carry. Export settings, source design data and tool implementation determine what is populated in a particular package. The recipient must still confirm support for the delivered output, and the release owner must verify whether BOM, approved alternates, assembly notes, variants, test requirements and controlled drawings are present and current.

What IPC-2581 is designed to transfer

IPC-2581, also described by its consortium as IPC Digital Product Model Exchange, is an open, global standard for exchanging printed-board and assembly manufacturing-description data. The Global Electronics Association describes an XML schema intended to communicate information for tooling, manufacturing, assembly and inspection between a designer and a manufacturing or assembly facility.

That scope makes IPC-2581 suitable for richer data exchange when both ends of the workflow support the output. It does not prove that a given manufacturer accepts the specific file produced by a given tool, nor that every optional data area has been populated. Confirm the recipient, validate the actual XML output and retain any project drawing, BOM, variant, test or acceptance input required by the agreed route.

Format, content, use and required supplements

FormatPackage and data roleManufacturing useStill verify or supplement
GerberSet of layer and related fabrication-data files; attributes and job information add machine-readable context when presentCAM image preparation, layer identification, drill/route and board-profile definition through the agreed setActual layer completeness, drill format, stackup, impedance, materials, notes, netlist, BOM, placement, variants and test requirements
ODB++DesignStructured job archive or directory that can relate fabrication, net, component, assembly and test dataIntegrated CAM/DFx handoff where the sender and receiver support the exported packageReceiver support, populated fields, drawing authority, approved BOM/alternates, variants, test limits and release revision
IPC-2581XML-based product-data exchange designed to describe printed-board and assembly manufacturing informationStandards-based design-to-manufacturing exchange where the receiving workflow supports the outputSchema/output validation, receiver support, populated content, project notes, acceptance data and controlled supplemental records

No row is a universal winner. The right release may use a Gerber set, an ODB++Design package or an IPC-2581 exchange, provided the recipient agrees, the export is inspected and the supplemental information closes the project-specific gaps.

Gerber, ODB++ and IPC-2581 compared by package structure, intended data and supplemental release checks
Original comparison graphic: “can carry” describes format scope; the release team must verify what a particular export actually contains.

How to choose the handoff format

1. Start with the receiving route

Ask the PCB fabricator or assembler which format it prefers for the specific project and whether the output from your EDA tool can be processed without conversion that discards required data. If support is uncertain, do not assume that a richer format is safer. The DFM review starts with a package the assigned engineering route can open and interpret consistently.

2. Inspect the exact exported result

Use an appropriate viewer or validation tool to open the files that will be transmitted, not only the native PCB design. Check board outline, layer order, origins, orientation, holes and slots, mask and paste, text, component data and visible stackup or net information where the format carries it. If the export does not represent the approved source, regenerate it.

3. Reconcile fabrication and assembly data

Compare the active revision and variant across fabrication data, BOM, Pick & Place, assembly drawing and any intelligent container. Reference designators and part identity should agree. If supply-chain changes are kept in a separate controlled BOM, do not assume an older embedded BOM remains authoritative.

4. Add the information the format does not settle

Manufacturing data still needs project intent: quantity and build stage, approved construction, special materials, controlled impedance, finish, panel requirements, component sourcing rules, test conditions, records and acceptance notes. Whether those items live inside the selected format or in controlled supplements, name their authority in the package manifest.

Data-package handoff flow

PCB data handoff flow from export through inspection, supplemental data, revision reconciliation and receiver confirmation
Original release flow: export, inspect, supplement, reconcile and confirm before archiving one controlled manufacturing package.

The same package should support quotation, engineering questions and approved release. If the quote used one stackup or BOM and production receives another, the format comparison is no longer the important issue—the uncontrolled revision is. Link this flow to the companion PCB DFM checklist so every finding has an owner before release.

Printable release-package checklist

Format and recipient

  • □ The receiving fabricator or assembler has confirmed the preferred format for this project.
  • □ The EDA export route and validation/viewer method are documented.
  • □ The exact transmitted export opens correctly and represents the approved board.

Fabrication data

  • □ Copper, mask, legend, paste where relevant, drill/route and closed profile data are present.
  • □ Layer order, units, origin, orientation and polarity are coherent.
  • □ Stackup, material, finished copper/thickness, impedance, surface finish and special notes are supplied where required.
  • □ A netlist or other comparison data is included if the agreed CAM/test route calls for it.

Assembly and product data

  • □ BOM, approved alternatives, reference designators and active variant are current.
  • □ Pick & Place, assembly drawings, polarity and bottom-side rotation agree with the board and BOM.
  • □ Programming, test access, conditions, pass/fail criteria and required evidence are defined where in scope.

Revision and release control

  • □ One manifest identifies the board, assembly, revision, variant and every authoritative file.
  • □ Duplicate or superseded exports have been removed from the archive.
  • □ The package reviewed for quotation is traceable to the package approved for manufacturing release.
  • □ Any conversion, interpretation or open assumption has an owner and disposition.

Use the Print / PDF button above to carry this checklist into the release meeting. It is a control aid; the selected format specification, customer requirements and agreed project package remain authoritative.

What format should you send PCBArise?
